MT 3502C 25 Pair Splicing Connector Module Water Proof 4002DWP / TR With Seal Box
Quick Details:
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: Melontel
- Model Number: MT-3502A
- Application: Telecommunication
- Material: Plastic
- Working temperature: -40°C ~ 80°C
- Color: Yellow
- OEM: Welcome
- Certification: ISO9001:2008
Description:
| Name : | 25 Pair Distribution Box |
| Country of origin : | Ningbo,China |
| Materia : | Plastic |
| Color : | Yellow |
| Capacity : | 25 Pair |
| Length : | 183mm |
| Weight : | 19g |
Introduction:
25-pair Communication Cable Connecting Module is used to connect 28-20AWG all plastic communication cables (diameter 0.32 « 0.80mm) through direct connection, bridge connection and multiple connection. It is widely used in communication circuit.
1. The contact is designed into tuning fork type and sheet joint so that connection will not be hampered.
2. irect connection, bridge connection and multiple connection can all be adopted. You do not bother to peel the protection coat and just use simple tool to have one time forming. The contact is sealed with organosilicon grease, proof against water and corrosion.
3. 28-20AWG(diameter 0.32«0.80mm) insulative solid copper and all plastic communication cables can be connected.
4. Operating environment: Temperature: -30 --+70;Relative humidity: < 85%;Atmospheric pressure: 70 --106kpa
5. Insulation resistance: insulation resistance between any two terminals ≥1 x 104MΩ¸ (normal temperature and normal humidity)
6. ontact resistance: contact resistance between connection card and leading line ≤5 mΩ¸
7. Electric strength: exert 2000 V DC (or AC 1400V) voltage between metal lead and insulative cover of the connected module, no damage to the module and no spark breakdown within 1 min.
